COPPER
Copper is a metal that can last for a thousand years, weather-resistant and weatherproof, easy to work both hot and cold.
Its unique natural colour loses its elegant initial shine acquiring different colours over time; initially it generates a brownish oxide until
it finally takes on the characteristic green or blue-green colouring.
This product is also available for our Lares® roofing systems.
Copper Strip
| COILS (Available also in little coils, inner Ø 300 mm - Stucco surface available) | ||
|---|---|---|
 |
Width | from 30 to 1250 mm |
| Thickness | 0,50 / 0,55 / 0,60 / 0,70 / 0,80 / 1,00 mm | |
| Coil weight | from 500 to 5000 kg | |
| SHEETS | ||
| Dimensioni | 1000 x 2000 mm / 1000 x 3000 mm | |
| Thickness | 0,60 / 0,70 mm | |
| COPPER BARS | ||
| Width | from 20 to 30 mm | |
| Thickness | from 1,50 to 5 mm | |
Copper Gutters
| Width mm | 0,50 mm | 0,55 mm | 0,60 mm | 0,70 mm | 0,80 mm | |
|---|---|---|---|---|---|---|
 |
Width 250 mm Bead 18 mm |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
| Width 280 mm Bead 18 mm |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
|
| Width 333 mm Bead 20 mm |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
2-3-4 5-6 m |
Conid : copper rainwaterpipes
| Dim. mm | 0,50 mm | 0,55 mm | 0,60 mm | 0,70 mm | 0,80 mm | |
|---|---|---|---|---|---|---|
 |
Ø 60 | 2 m | 2-3 m | |||
| Ø 75 | 2-3-4 m | |||||
| Ø 76 | 2 m | 2 m | ||||
| Ø 80 | 1-2-3-4-6 m | 3-4 m | 2-3-4 m | 2 m | 2 m | |
| Ø 87 | 2 m | 2 m | ||||
| Ø 100 | 2-3-4-6 m | 2-3-4-6 m | 2-3-4-6 m | 2 m | 2 m | |
| Ø 120 | 4 m | 2-3-4 m | ||||
| 80x80 | 4 m | 4 m | 2 m | |||
| 100x100 | 4 m | 2 m | ||||
| 60x90 | 4 m |
Euround : copper elbows
| Welded elbows | 0,50 mm | 0,60 mm | 0,70 mm | |
|---|---|---|---|---|
 |
Ø 60 | 72° - 85° | ||
| Ø 75 | 72° - 85° | |||
| Ø 76 | 72° | |||
| Ø 80 | 40° - 72° - 85° | 40° - 72° - 85° | ||
| Ø 87 | 72° | |||
| Ø 100 | 40° - 72° - 85° | 40° - 72° - 85° | ||
| Ø 120 | 72° | |||
| Folded elbows | 0,50 mm | 0,60 mm | 0,70 mm | |
| 80x80 | 72° | |||
| 100x100 | 72° |
Copper welded double elbows
| Ø mm | ||
|---|---|---|
 |
Ø 80 | |
| Ø 100 |
Go.Al : copper extensible elbows
| Item description | Dimensions mm | Ø mm | |
|---|---|---|---|
 |
GO.AL 1 | from 300 to 400 | Ø 80 - 100 |
| GO.AL 2 | from 400 to 500 | Ø 80 - 100 | |
| GO.AL 3 | from 500 to 800 | Ø 80 - 100 | |
| GO.AL 4 | from 800 to 1000 | Ø 80 - 100 |
Copper roofing accessories
 |
Perforated strip | Height 165 / 200 / 250 / 330 / 1000 mm |
 |
Endcaps | Width 280 / 333 mm |
 |
Supports | Width 280 / 333 mm |
 |
Gutter outlets | Width 280/80 mm - Width 280/100 mm Width 333/80 mm - Width 333/100 mm |
 |
Outlets for soldering, flat Outlets for soldering, halfround |
Ø 80 - Ø 100 mm Ø 80 - Ø 100 mm |
 |
Corners | Width 280 mm - Bead 18 mm - inner/outer Width 333 mm - Bead 20 mm - inner/outer |
# Further dimensions available on demand.
